3 Finger Round Body Pneumatic Gripper MHS for Round Workpiece

NTA series MHY 180° pivot open and close type mini pneumatic gripper also called pneumatic finger equipped with a double acting piston attached to a cross bar by a connecting rod. The linear movement from the cylinder is transfered  through a double toggle link mechanism to angular movement of the jaws.Piston body is hard anodized, there are four  sensor slots on two surfaces, pivot pins made in hardened steel reduces friction and wear.If you want to buy pneumatic collet gripper, please feel free to contact us sales@titan-automation.com, telephone&whatsapp number 008613616569784

NTA series MHC angular small pneumatic grippers has compact body and light weight, it is high dgree of mounting flexibility. Bore diameter covers 6mm, 10mm, 16mm, 20mm, 25mm. Automatic angular pneumatic holder gripper is manufactured to process demanding workflow requirements in food&beverage equipment, medical instruments, chemical industry and office automation. The gripper cylinder includes a double acting pneumatic piston with levers. The cartridge style structure provides a greater gripping force than traditional designs.We have more automation components available for your equipments, please contact email sales@titan-automation.com, telephone&whatsapp number 008613616569784

NTA series MHZ mechanical gripper have true parallel motion that is actuated by a double acting air cylinder, it has linear guide improves rigidity and accuracy, MHZ parallel style has compact design and light weight with high dgree of mounting flexibility. Finger positions can be selected,  bore diameters cover 6mm, 10mm, 16mm, 20mm, 25mm, 32mm, 40mm. The NTA series MHZ pneumatic cylinder gripper is widely used on industrial robots, general machines, bottling, conveyer (handling) equipment, biofuels, packaging machines etc. Please contact us for different types of pneumatic linear grippers, email sales@titan-automation.com, telephone&whatsapp number 008613616569784

NTA series MHL wide parallel open and close air gripper has linear guide improves rigidity and accuracy. The series MHL parallel grippers utilize independent pistons to open and close its jaws, this long stroke pneumatic gripper is designed for applications that need to grip a big width object, that requires the long travel, the new version MHL motion is synchronized by a rack and gear construction. The double construction makes the pneumatic expanding gripper with a large holding force. Piston has a magnet ring for position sensing. Please feel free to contact us sales@titan-automation.com, telephone&whatsapp number 008613616569784
