Adjustable Angle Rotary Air Actuators NTA MSQ Install at Tight Spaces

NTA MPG series panel type compact pneumatic cylinder, is a space-saving and light weight actuator, bore diameter covers 6mm, 8mm,10mm, 12mm, 16mm. Cylinder body is thin profile&flexible mount design, piston has magnetic ring, thus you can use them together with NTA sensors and connect to PLC to activate extending and retracting. The cylinder is designed with bumper cushions both on front and rear cap. Welcome to call us for more information, telephone&whatsapp number 008613616569784

With a standard round body air cylinder, the piston rod can rotate freely when it extends and retracts, in most of the applications this rotation does not cause any problem but if the application doesn't  allow rotation, it can be a matter. Hex piston rod non rotating air cylinders provide the solution to avoid piston rotation by using hexagon piston rod, it helps to guarantee the repeatability precision of the linear drive.The hexagon piston rod with a through hole is blackened to prevet from corrosion, 3/4'' 0.75in bore diameter, its stainless steel non-repairable design provides a maintenance-free, long-lasting performance in a wide range of applications. Welcome to contact NTA team for standard and cusomized cylinders sales@titan-automation.com, telephone&whatsapp number 008613616569784

NTA series CU free mount pneumatic cylinder,is space-saving with multiple surfaces capable of mounting directly. Offered in rich variations, bore diameter covers 6mm, 10mm, 16mm, 20mm, 25mm, 32mm.  Series CU free mount pneumatic cylinder uses PU or NBR sealings to reach good sealing performance. The multiple surface direct mounting with a square body and no brackets allows the freedom of the mounting surface.This enables space-saving designs for equipment. Being shorter and lighter, it has variety of ways and compact enough to be screwed on machines directly.Axial mounting, vertical mounting and lateral mounting. There are 4 auto switch slots on 2 surfaces. If you need to know more information about NTA pneumatic pistons, please kindly email to jet@titan-automation.com

NTA MXS series mini slide table pneumatic cylinder is an air slide table that is ideal for precision assembly work, it is high rigidity and high accuracy, smooth movement without looseness has been achieved through the adoption of a cross roller guide.Compact and lightweight. bore diameter ranges 6mm, 8mm, 12mm, 16mm, 20mm, 25mm.  NTA MXS linear slides uses PU or NBR sealings to reach good sealing performance, both with magnet ring or without magnet ring types are optional, auto switch slots are located on 2 surfaces. Mini slides cylinders have a compact design, can assist in installation in tight space and can be optimally configured for virtually any automated operating task. NTA manufacturing welcomes the opportunity to custom design a cylinder to meet your exact specifications and requirements.
