MSQ Slotted(non return) Brass/Metal Elbow Type/Universal Type/Push-lock Type Throttle Control Valve/Air Flow Control Valve/Pneumatic Flow Control Valve/Air Flow Controller/Flow Control Regulators In China
MSQ Slotted(non return) Brass/Metal Elbow Type/Universal Type/Push-lock Type Throttle Control Valve/Air Flow Control Valve/Pneumatic Flow Control Valve/Air Flow Controller/Flow Control Regulators
NTA MSQ slotted(non return) brass/metal elbow type/universal type/push-lock type throttle control valve/air flow control valve/pneumatic flow control valve/air flow controller/flow control regulator is used to control action speed of pneumatic cylinder/pneumatic actuators by control air flowrate in the pneumatic system, it precisely permit the optimal rate of airflow for the smooth cylinder movement of driving devices, the compact design provides a comparable range of speed as the conventional speed control do. Electroless nickel plated type is standard. Uni-directional airflow is available for either exhaust or inlet flow control methods. 360°swivel piping is possible. It is suitable for use with nylon and urethane tube, large retaining force, it can be used for a wide range of pressures from a low vaccum up to a high pressure of 1.6MPa/232PSI, long lifetime, air through and break life cycle number reaching 17.4 million cycles, it is 2.8 to 348 times of lifetime from other Chinese fitting suppliers(0.05 to 6.3 millions cycles). The air fitting structure(push in fitting/one touch fitting) is quick installation, simple and flexible, space-saving, easy to connect tube by one touch.
